Controlling range of operating lever

±20°～± 25°（From center position）

Operating force

With spring return device: automatically return to center Approx. 1～2.5N (100～250gf), With rubber cover: Approx. 1～5.5N (100～550gf))

Operating temperature range

-20℃～+60℃

Vibration

10～55Hz 98 m/s2

Shock

294 m/s2

Mechanical life expectancy

Approx. 2,000,000

Mass

Approx. 100g

Potentiometers mounted

Special conductive plastic resistive element is exclusively used for 30JL series

Resistance value

10KΩ±20%

Independent linearity tolerance

±5%

Electrical rotating angle

Approx. 40°

Power rating

0.1W

Output smoothness

<Against input voltage 0.2%

Contact resistance variation

<6% C.R.V.

Resolution

Essentially infinite

Dielectric strength

1 min（500V.A.C.）

Insulation resistance

>1000MΩ（500V.D.C.）

Other Mechanical Specifications

Dust proof rubber, sub-panel for mounting, special knobs shapes and detent mechanism

Other Electrical Specifications

Micro switch, alteration of potentiometer's total resistance value, intermediate tap of potentiometer and switch incorporated inside knob
